Shaft diameter | Block bearing model | shapesize(mm) | Bolt specifications | Bearingmodel | Block model | weight (kg) |
d | L | P | A2 | t | N | W | S | B1 |
(min.) | (mm) |
1/2 5/8 11/16 | 12 15 17 | SAPFT201 201-8 202 202-10 203 203-11 | 82 | 64 | 7 | 2 | 7,5 | 29 | 6,5 | 28,6 | 1/4 | M6 | SA201 201-8 202 202-10 203 203-11 | PFT203 | 0,29 |
3/4 | 20 | SAPFT204-12 204 | 91 | 71 | 8 | 2 | 9 | 33 | 7,5 | 30,9 | 5/16 | M8 | SA204-12 204 | PFT204 | 0,31 |
7/8 15/16 1 | 25 | SAPFT205-14 205-15 205 205-16 | 95 | 76 | 9 | 2 | 9 | 35 | 7,5 | 30,9 | 5/16 | M8 | SA205-14 205-15 205 205-16 | PFT205 | 0,41 |
1-1/8 1-3/16 1-1/4 | 30 | SAPFT206-18 206 206-19 206-20 | 113 | 90 | 9 | 2,5 | 10,5 | 38 | 9 | 35,7 | 3/8 | M10 | SA206-18 206 206-19 206-20 | PFT206 | 0,67 |
1-1/4 1-5/16 1-3/8 1-7/16 | 35 | SAPFT207-20 207-21 207-22 207 207-23 | 122 | 100 | 10 | 15 | 10,5 | 45 | 9,5 | 38,9 | 3/8 | M10 | SA207-20 207-21 207-22 207 207-23 | PFT207 | 0,87 |
